Product Details:

Place of Origin: China
Brand Name: Huayide
Certification: CE&ISO
Model Number: HYD-CFR

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: can be negotiable
Packaging Details: Plastic banding+Stretch film wrapped,easy loading and unloading with standard forklift truck or pallet jack .
Delivery Time: 10-20 working days
Payment Terms: L/C, T/T
Supply Ability: 900000KGS PER Month
Get Best Price Contact Now

Detail Information

Height: 1500-2500mm Structure: Easy Assemble
Layer: 4 Layers Packaging: Packaging
Delivery Time: 15 Days Surface Treatment: Powder Coating
Product Color: Orange,Gray,White,Blue,Black,or Customized
Highlight:

Medium Duty Rack

,

Carton Box Storage rack

,

Long Span Rack

Product Description






Medium Duty Rack





B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 0



Medium duty rack/shelf belongs to warehouse storage racking systems.It can be adjusted by each 50mm,and the load capacity can be reach 200~500kg.The beam is "P" type beam,whose height mataches with that of the layer board.





B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 1






Medium Duty Rack · Warehouse Storage Rack · Made In China






Structural Principles

——





B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 2



B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 3



B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 4



B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 5



Main and sub frame / Saves cost save space
The main frame has two columns frames, which can be used independently,add on rack cannot be used alone, which must be used with the main rack.



B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 6



Shelving Board / Reinforcement Ribs
The spot-welded reinforcing ribs at the bottom of the shelf board increase the focus of the laminate and prevent the shelf board being deformed and make it much stronger.





Trapezoidal support
Diagonal bracing is added to the shelf, which conforms to the mechanical theorem and ensures stable load-bearing.



B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 7



Upright Frame Design
The upright frame are designed with butterfly holes and are connected to the buckles on the beam pendants, which saves time and effort during installation and is easy to disassemble.The shelf layer height can be adjusted according to customer's needs.



B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 8



Assembled column piece
Our upright frames are assembled with bolts instead of welding, which can fit in more qty in the shipping container and save the shipping freight.





Medium Duty Rack · Warehouse Storage Rack · Made In China






Sizes For Choose

——



Load Capacity Sizes(L*W*H)mm Specification
100~150KG/Layer 800*400*1800*4 layers, 800*500*1800*4 layers,
1000*400*2000*4 layers, 1000*500*2000*4 layers,
1200*400*2000*4 layers, 1200*500*2000*4 layers,
1500*400*2000*4 layers, 1500*500*2000*4 layers,
1500*600*2000*4 layers, 2000*400*2000*4 layers,
2000*500*2000*4 layers, 2000*600*2000*4 layers,
upright:30*50*0.7, beam:30*50*0.5,
layer plate:0.3,
200KG/Layer 1200*400*2500*4 layers, 1500*500*2000*4 layers,
1500*600*2000*4 layers, 2000*500*2000*4 layers,
2000*600*2000*4 layers,
upright:40*80*0.7, beam:40*60*0.6,
layer plate:0.3,
300KG/Layer 1000*500*2000*4 layers, 1000*600*2000*4 layers,
1500*500*2000*4 layers, 1500*600*2000*4 layers,
2000*500*2000*4 layers, 2000*600*2000*4 layers,
upright:40*80*1.0, beam:40*60*1.0,
layer plate:0.4,
400KG/Layer 1500*600*2000*4 layers, 2000*600*2000*4 layers, upright:40*80*1.2, beam:40*60*1.2,
layer plate:0.6,
500KG/Layer 2000*600*2000*4 layers upright:40*80*1.5, beam:40*60*1.5,
layer plate:0.7,
1000KG/Layer 1000*500*2000*4 layers, 1500*500*2000*4 layers,
2000*500*2000*4 layers, 2000*600*2000*4 layers,
upright:60*80*1.5, beam:50*80*1.5,
layer plate:1.0,



Medium Duty Rack · Warehouse Storage Rack · Made In China








CASE



B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 9

B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 10



Medium Duty Rack · Warehouse Storage Rack · Made In China





B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 11

B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 12



Medium Duty Rack · Warehouse Storage Rack · Made In China



B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 13

B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 14





Medium Duty Rack · Warehouse Storage Rack · Made In China





B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 15

B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 16



B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 17



B16 Medium Duty Rack  Carton Box Storage rack Long Span Rack Warehouse Storage Racking 18



Medium Duty Rack · Warehouse Storage Rack · Made In China






Ensure the quality of Huayide racking products



1 The raw material of the shelf is customized from China's large steel group of high quality carbon steel, durable and strong, to ensure the quality of the product from the source.
2 The shelf welding adopts dioxygen protection welding, the welding joint has good cracking resistance, small welding deformation, beautiful forming, and does not need slag cleaning.
3 Each column and beam of the shelf are designed by professional personnel with professional technology and cut by professional equipment, so as to ensure the accurate size of the shelf.
4 Professional spray before treatment, oil removal, rust removal, phosphating, powder, and then in high temperature oven baking molding, wear-resistant, rust proof.
