ODM Drive Through Racking System
Product Details:
| Place of Origin: | China |
| Brand Name: | Hua Yide |
| Certification: | CE&ISO |
| Model Number: | Drive in Racking |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000KGS |
|---|---|
| Price: | can be negotiable |
| Packaging Details: | Plastic banding+Stretch film wrapped,easy loading and unloading with standard forklift truck or pallet jack . |
| Delivery Time: | 10-20 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 900000KGS per Month |
|
Detail Information |
|||
| Name: | Drive In Steel Rack Heavy Duty Storage Shelf For Cold Warehouse Forklift Drives Into Pallet Rack | Application Environment: | Normal Temperature Or Freezer |
|---|---|---|---|
| Finish: | Powder Coated Or Galvanized | Design Service: | Free CAD Service Available |
| Back-up Service: | Installation Drawing/On Site Instruction | HS CODE: | 73089000 |
| Scale: | Heavy Duty | OEM: | Available |
| Free Sample: | Available (Delivery Cost On Buyer) | Weld: | Weld For Automatic Welding |
| High Light: | ODM Drive Through Racking System,Drive Through Racking System 1200x800mm,ODM Drive Through Racking |
||
Product Description
High Space Utilization Narrow Aisle Drive In Racking System Design
Warehouse storage drive in rack can be used for forklift to enter and access goods. It is suitable for storing goods with large quantity. In addition to the location near the channel, the forklift truck needs to enter the rack to store goods. Usually, no more than 7 location depths are recommended. In order to improve the running speed of the forklift, the configuration guide rail can be selected according to the actual needs, and the utilization rate of the storage space of the drive in rack can be increased by more than 30% compared with the normal rack.
Applications:
1. Cold room warehouse
2. Dairy industry
3. Food industry
4. Tobacco industry
1. One of the most economical, High Density, storage systems available today.
2. Best suited for use on large quantities of "Like Items".
3. Uses a "Last In - First Out" method of recovery, and thus is much better suited to items with a long shelf life.
4. Uses a "Common entrance and exit", so access need only be from one side.
5. Uses "Separate entrances and exits" so access needs to be on both sides.
6. The forklift drives directly into the rack for storage or recovery, allowing storage of 2 or more pallets deep.
7. Used for High-Density Storage.
| Loading | 2000KGS/Pallet (Max) |
| Stacking layers | Customized |
| Demensions | standard pallet size 1200x1000/1200x1200/1100x1100/1200x800mm |
| Material | Q235 |
| Rack size | customized |
| Type | Last in First out or First in First Out |
| OEM | Available |
| Pallets deep | 3-7 pallets depth ,or customized |
| Parts | Upright, bracket Beam, single& double side bracket, top beam etc. |
| Color | Blue + orange, customized |
Packing & Delivery:
FAQ:
1. Q: What's your trading terms?
1) Payment terms: T/T 30% deposit after order confirmed, 70% balance paid against bill of lading.
2) Lead time: normally in 20-25 days after deposit received.
3) Sample policy: samples are always available for each model. Samples can be ready in 7-15 days once payment received.
4) Shipping port: Shanghai / Nanjing Port
2. Q: What is your service?
1) Your inquiry related to our products or price will be replied in 12 hours.
2) Well-trained and experienced staffs to answer all your inquiries in fluent English.
3) OEM & ODM, any your customized racking we can help you to design product.
4) We have very experienced professional engineers to make best solutions.
3. Q: Do you have any reference for assembling the products ?
Yes, we offer assembly manual and we can provide you instructor engineer to your warehouse if needed.
4. Q: What's the international trading process?
Design drawing → Confirm drawing → Quotation → PI → Confirm PI → Arrange 30% deposit → Manufacture → QC inspect → Pay balance →Shipping.
5. Q: What's your advantage?
1) rush order we can fast delivery.
2) factory direct sale competitive price.
3) experienced professional engineers.
6. Q: How does charge tooling fee (cost of opening new mold)?
For the production of necessary tooling requirement, charges the cost before the first order for opening new mold, and the cost will be partially or fully refunded after certain quantity of orders.
