Roll-Out Sheet Rack

—

Customized solutions
Provide customized solutions based on actual user needs to meet storage needs in different scenarios.

Fast delivery
Our self-operated factory quickly completes project delivery from design, manufacturing to installation services in one stop.

Roll Out Sheet Rack · Heavy Duty  Storage Rack · Made In China

The drawer type panel rack is used to store metal sheets such as iron sheets, aluminum sheets, stainless steel sheets, or non-metallic sheets such as wooden boards and plastic sheets. Commonly used in the construction manufacturing and processing industry.
Use a drawer style board rack to avoid deformation and curling of the board, ensuring worry free storage. Convenient access to boards of different specifications and sizes on the lower level, making storage more convenient.

Multi layered drawers are classified neatly: The number of drawers depends on your personal needs and is stored in categories for easy inventory.
Door opening and closing design: With strong load-bearing capacity and good stability, you can use the entire lobby space to store large quantities of boards in a narrow space.
Crane suction cup access: convenient for crane use, tailored to clean the environment, and can achieve 360 degree operation to save time and labor costs.

Roll Out Sheet Rack · Heavy Duty Storage Rack · Made In China

Positioning support

—

The positioning support at the front end of the door is simple and easy to operate, and can adapt to various storage ground environments. The bottom of the positioning support at the front end of the door is specially designed to increase the support area, reduce the pressure with the ground, and reduce damage to the warehouse ground.

Roll Out Sheet Rack · Heavy Duty Storage Rack · Made In China

Brand bearing

—

Using multiple branded bearings, with three branded bearings on each side, not only ensures smooth and effortless use, but also reduces track pressure, making the structure more scientifically safe.

Transmission: Guide wheels are installed on both sides of the drawer, which are divided into driving wheels and driven wheels according to different driving modes. The driving end is driven by a reducer, a reduction box, and a sprocket chain, and is transmitted to the guide wheels through a transmission rod. The guide wheels run on tracks to move materials from the cargo space to the outside of the shelf. Vertical storage and retrieval operations can be achieved using tools such as a crane.

Roll Out Sheet Rack · Heavy Duty Storage Rack · Made In China

Active stainless steel door hinge

—

The door hinge is made of stainless steel material, finely cast, and safe and reliable to use. The movable door hinge not only has low maintenance costs, but also extends the service life of the product. The opening angle of the movable door shaft hinge can be adjusted, and the opening angle is fixed to prevent tipping and reduce safety hazards during use.

Roll Out Sheet Rack · Heavy Duty Storage Rack · Made In China

The maximum storage capacity of each layer is 5t,
and only 5-10N shear stress is required.

—

Roll Out Sheet Rack · Heavy Duty Storage Rack · Made In China

Provide a more comprehensive

warehousing solution

—

Three-dimensional storage:
1)As the name implies, three-dimensional storage is to convert the flat storage on the ground into three-dimensional storage in three-dimensional space by stacking multiple layers through the use of high space.
2)Three-dimensional storage can maximize the use of space height, greatly improve storage efficiency, reduce storage area, and significantly reduce storage costs.
3)The drawer-type plate rack solves the original old floor-laying solution through a multi-layer structure, thereby solving the problems of storage efficiency and storage cost.

Visual management:
1)Visual management simply means that the objects to be managed are presented in a clear way

2)At present, most companies cannot clearly classify and identify materials and manage them independently due to storage conditions and material characteristics. Problems such as multi-layer stacking of materials and labels being covered and worn make identification difficult and it is difficult to conduct quick and effective retrieval. As a result, the retrieval efficiency is low, the time is too long, and more people are involved in material management operations. This results in low efficiency, time, and cost indicators.
3)Drawer-type plate racks are stored independently through multiple compartments. All compartments can be independently stored and retrieved, and independent compartments are independently labeled. This greatly improves retrieval efficiency, shortens material storage and retrieval time, and reduces personnel input. It truly achieves speed, accuracy, and economy.

Independent storage and access in layers:
1)Independent storage and access in layers means that materials of different specifications and models are classified and stored independently, so that they can be easily taken. In actual use in our warehouse, materials of different specifications are stored in a messy manner, which makes picking difficult. Using traditional cabinet storage, it is difficult to access materials below.
2)The drawer-type plate rack has multiple layers of independent cargo grids, which can classify and store materials of different specifications into independent units. It can realize the arbitrary storage and access of plates, improve the circulation efficiency of the warehouse, and make picking convenient

Folding door rail: The drawer-type plate rack folds the external rail and hides it on the side of the plate rack. The rail door only needs to be opened when storing and accessing. Compared with fixed door rails, the storage and access work station requires a six-meter passage, which greatly saves storage area.

Roll Out Sheet Rack · Heavy Duty Storage Rack · Made In China

Product Advantages

—

T-type single-sided wheel with tilt structure

Smooth Pulling:
1)The overall structure of the drawer-type plate rack adopts finite element analysis, and the local components are subjected to structural analysis and mechanical calculation. The shear stress design of pulling out during use is easier and more reasonable.
2)The T-shaped single-sided wheel with an angled structure is adopted to ensure the safety of the drawer while having a guiding function, making the drawer run smoothly and safely.

Safe and stable:

1)Each track door is equipped with 2 sets of angle limit devices, which can locate the door opening angle when opening the door, ensure the straightness of the main track and the door track, and ensure the safety of the drawer after it is pulled out.
2) Eight safety limit plates of 8mm or more are configured around the drawer (2 on one side) to ensure that the plate will not slide out of the drawer easily.
3) The corner brace method is used to form a stable triangular structure to ensure the stability of the drawer door frame structure, with higher strength and better stability.
4) Six 16mm thickened side panels are added to the top frame to increase the connection strength and stability of the drawer top frame and the column side frame.

Durable:

1)The new door shaft structure design uses stainless steel material and thrust bearings. The assembled door shaft structure can be adjusted up and down, left and right. The new design is safer and more durable.
2)The orange-grain epoxy resin powder is electrostatically sprayed and high-temperature leveling and curing is used. It has better protection than conventional spray painting and plastic spraying, and the surface is more beautiful after the orange-grain powder is cured.
3)The track part that is easy to wear is treated with galvanizing technology. The surface is not easy to be damaged after long-term use and is more durable. The galvanized track has a more industrial aesthetic.

Low maintenance cost:

When planning storage, a certain passage needs to be reserved between the shelves for the storage and retrieval of goods. The use of drawer-type plate racks allows vertical storage and retrieval operations, eliminating forklift operations and saving 4-6 meters of forklift operation passages.
