Radio Shuttle Racking Pallet Runner Rack
Product Details:
| Place of Origin: | China |
| Brand Name: | Huayide |
| Certification: | CE&ISO |
| Model Number: | HYD-SR |
| Document: | Radio Shuttle Pallet Rack.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plastic Film Protect&Sponge |
| Delivery Time: | Quantity(Kilograms)1 - 10000: Lead Time (Days) 20 ; Quantity(Kilograms)>10000: To Be Negotiated |
| Payment Terms: | L/C, T/T |
| Supply Ability: | <50000 Kilograms |
|
Detail Information |
|||
| Name: | Radio Shuttle Racking | Product Category: | Semi-Automatic Racking |
|---|---|---|---|
| Material: | Q235 Steel | Loading Capacity: | Up To 1500 Kg/Pallet |
| Surface Treatment: | Powder Coating/Galvanized | Principal: | Fifo&Filo |
| Space Utilization: | 80% Above | Operation Temperature: | 0°C～+ 45°C |
| Highlight: | Radio Shuttle Racking,pallet runner rack system,Radio Shuttle Pallet Racking |
||
Product Description
Radio Shuttle Racking
——
Strong bearing capacity, easy installation, expansion space & durability.
Operating temperature: -30°C to +45°C
Warehouse radio shuttle racking system, is also known as the pallet shuttle system and radio shuttle rack, evolved from the drive in rack system, but the forklift does not need to drive into the rack, which overcomes the shortcomings of the slow rack access speed and poor stability of the rack system. , Realizing remote control automation of access.
When the goods are stored, the pallet goods are placed on the forefront part of a certain row of guide rails in a certain row of the shelf area by a forklift, and the shuttle car is wirelessly remotely controlled. The shuttle car transports the pallet goods to the depth. The pallet goods in the deep shelf are moved to the port of the guide rail, and then the pallet goods are removed by a forklift
Warehouse radio shuttle racking system is characterized by extremely high storage space utilization, stable and reliable system, and semi-automation. It is suitable for the storage of large quantities of small varieties of goods, such as food, beverage, and refrigeration industries. The linkage can also be carrie out by the cooperation of the child car and the mother car, and the periphery can also be carried out by a lifter or a stacker, thereby building a high-density storage system with a higher degree of automation.
Radio Shuttle Racking · Warehouse Storage Rack · Made In China
Product Structure
——
| 1 ) Column | 2 ) Adjustable feet | 3 ) Frame Spacer | 4 ) Diagonal Brace |
| 5 ) Lateral Bracing | 6 ) Rail support Beam | 7 ) Rail Bracket | 8 ) Pallet Rail |
| 9 ) Pallet Guide Plate(Entry Guide) | 10 ) Shuttle Cart Stopper | 11 ) Lateral Bracing | |
| 12 ) Forklift Stopper | 13 ) Radio Shuttle | 14 ) Remote Control | |
Radio Shuttle Racking · Warehouse Storage Rack · Made In China
Product Advantage
——
● Cost Effective And Time-Saving
1)Forklifts are not required to enter the racking area, shuttles can work continuously while operator handles the pallet with forklift.
2)Compared with other types of shelves, the overall investment is less, for example: warehouse lighting requirements.
● High-Density Storage
Maximum floor space utilization, the aisle for forklift in selective racks is eliminated, space utilization increased almost 100%.
Radio Shuttle Racking · Warehouse Storage Rack · Made In China
● Strong Bearing Capacity: Up To 1.5t Above: Up to 1500 kg/pallet could be handled in the system
● The pallet configuration can go up to 40m deep in the lane
● Easy Installation And Maintenance
● Strong & Durable, Beautiful Rust Proof
The shelves are made of cold-rolled steel material, which is electrostatic sprayed after pickling and phosphating at high temperature.
Radio Shuttle Racking · Warehouse Storage Rack · Made In China
● Built In Safety Feature : Built in safety feature like pallet guide centralizers, rail end stoppers, photoelectric sensors, etc.
Radio Shuttle Racking · Warehouse Storage Rack · Made In China
Accessing Goods
——
● High Precision Automatic Storage & Pickup:Automatically handles pallet picking and retrieval with high precision.
» Radio shuttle racking system is a semi-automated, high-density pallet storage solution, working with radio shuttle cart and forklift.
» With a remote control, operator can request radio shuttle cart to load and unload pallet to requested position easily and quickly.
Radio Shuttle Racking · Warehouse Storage Rack · Made In China
Secure Storage And Pickup
——
Shuttle cars enter the rack / The shuttle was loaded with cargo
Use the shuttle to store goods / Shuttle car return
Single Side Access / FILO, More Storage Capacity / Through Access / FIFO, Two-Sided Roadway Access
Radio Shuttle Racking · Warehouse Storage Rack · Made In China
Product Type
——
»» Room Temperature Warehouse (Two Way Radio Shuttle Racking) »»
Operating temperature: 0°C to +45°C
»» Cold Storage (Two Way Radio Shuttle Racking) »»
Operating temperature: -1°C to -30°C
»» Explosive Proof Warehouse (Two Way Radio Shuttle Racking) »»
Gas explosion-proof storage Class B
»» Room Temperature Warehouse ( Four Way Radio Shuttle ASRS ) »»
Operating temperature: 0°C to +45°C
»» Cold Storage Warehouse ( Four Way Radio Shuttle ASRS) »»
Operating temperature: -30°C to 0°C
»» Radio Shuttle Cart And Carrier AS/RS »»
»» Radio Shuttle Rack + Stacker Crane AS/RS »»
Radio Shuttle Racking · Warehouse Storage Rack · Made In China
Product Packaging And Transportation
——
Radio Shuttle Racking · Warehouse Storage Rack · Made In China
Ensure the quality of Huayide racking products
—
| 1 | The raw material of the shelf is customized from China's large steel group of high quality carbon steel, durable and strong, to ensure the quality of the product from the source. |
| 2 | The shelf welding adopts dioxygen protection welding, the welding joint has good cracking resistance, small welding deformation, beautiful forming, and does not need slag cleaning. |
| 3 | Each column and beam of the shelf are designed by professional personnel with professional technology and cut by professional equipment, so as to ensure the accurate size of the shelf. |
| 4 | Professional spray before treatment, oil removal, rust removal, phosphating, powder, and then in high temperature oven baking molding, wear-resistant, rust proof. |
