Electric Mobile Pallet Rack Rail Free Racking Warehouse Storage Rack Electric Mobile Racking

Electric Mobile Pallet Rack Rail Free Racking Warehouse Storage Rack Electric Mobile Racking

Product Details:

Place of Origin: China
Brand Name: HuaYide
Certification: ISO&CE
Model Number: EMPRRFR

Payment & Shipping Terms:

Minimum Order Quantity: 1 project
Price: Negotiatable
Packaging Details: Plastic banding+Stretch film wrapped,easy loading and unloading with standard forklift truck or pallet jack
Delivery Time: around 6 weeks receipt signed
Payment Terms: L/C, T/T
Supply Ability: 12,000 tons per year
Get Best Price Contact Now

Detail Information

Features: Automated High-Density Storage Product Name: Electric Mobile Racking System(Rail-Free)
Product Category: Semi-automated Storage System Material: Steel
Application Environment: Normal Temperature,Cold Storage,Explosion Proof Warehouse Surface Treatment: Powder Coated
Unit Load: Max.32ton Unit Control Mode: Manual, Automated, Centralized System, Remote Control
Highlight:

Electric Mobile Pallet Rack

,

Electric Mobile Racking

,

Electric Mobile Pallet Rack

Product Description



Electric Mobile Racking
——      Rail-Free   ——



Electric Mobile Racking System



  • The electric mobile racking system is ideal for users who want to expand storage but are limited by the floor space in the warehouse. The maximumly used floor space render the mobile racking system a perfect choice for cold storage.
  • Only one channel, the space utilization rate is very high. The bearing trolley is driven by the motor, and the trolley is placed with beam type shelves and cantilever shelves. The frequency conversion speed regulation makes the shelves extremely stable from start to brake, and the safety is guaranteed.
  • According to the bearing, electric mobile racking system can be divided into heavy, medium and light three kinds, generally heavy racks use electric control for easy movement, light and medium generally use hand movement. The shelf system can greatly improve the utilization rate of the warehouse area, so it is widely used in the media, library, finance, food and other industry warehouses.










Electric Mobile Racking · Warehouse Storage Rack · Made In China






Product Advantage

 —

  • No ground construction required, no protrusions on the ground for easy forklift traffic;
  • No damage to existing ground, simple construction, easy to move facilities;
  • No track construction required, short delivery trial period; about 10-15 days shorter than rail type, easy operation;
  • Maintenance: polyurethane wheels are easier to maintain; direct drive without chain is more reliable;

Comparison

Racking type Mobile storage racking ASRS
Design Racking almost the same as pallet racking Similar as drive in rack or pallet racking
Automatic mode Semi-automatic Fully-automatic
Complexity Simple A little bit more complicated
Maintenance Normally Frequently
Space utilizaton 65 ~ 70% 70%~85%
Control mode Auto / Remote control / Manual Computer networking





Applicable Scope

 —

 Suitable for cold storage, explosion-proof and need higher warehouse utilization situations.





Technical Specifications

 —



System Type Unit Load Speed Motor Power Power Control Mode
Rail-free Max.32ton Unit Max10m/min 0.4-1.5KW

AC380V(50/60Hz)

AC200/220V

Manual, Automated

Centralized system

Remote Control





Electric Mobile Racking · Warehouse Storage Rack · Made In China






Structural Principles





Trackless electric mobile rack refer to the forklift entrance and exit ground without tracks on the shelves. However, on the other side of the rack, there is a guide rail that guides the movement of the rack.



Electric Mobile Pallet Rack Rail Free Racking Warehouse Storage Rack Electric Mobile Racking 1









Floor Guide

On one side of the mobile shelving, there is one set of guided angle rail to keep the mobile shelving moving in line. Under each mobile base there is no more floor rail track required for the movement of the shelving rack.



Electric mobile racking system



Guide Rail Mode
Single operation , in the back of the installationguide rail , does not obstruct the traffic.
High performance polyurethane wheel
The noise is smalland no damage to the ground.
The construction period is short , no concrete constructionand solidification time.



Electric Mobile Pallet Rack Rail Free Racking Warehouse Storage Rack Electric Mobile Racking 3



Electric Mobile Pallet Rack Rail Free Racking Warehouse Storage Rack Electric Mobile Racking 4



Safety Equipment

Huayide Electric Mobile racking have obtained CE certification issued by European authorities,In order to prevent safety problems caused by people or forklifts entering the aisle when the racking are running, the electric mobile racking are equipped with multiple safety devices.

During the operation of the shelf, if there is a foreign object in the aisle, or a person, a forklift enters the aisle, the electric mobile shelf will automatically stop running and issue an acoustic and visual alarm.



Electric mobile racking system



Advantages of electric mobile racking system:
1 ) Suitable for cold storage, explosion-proof and need higher warehouse utilization occasions;
2 ) No chain transmission, simple and reliable structure, low failure rate
;
3 ) By computer control, automatic, semi-automatic, manual function;
4 ) Can realize single column movement; multi-column group movement can be realized. Uniform dispersion can be achieved
;
5 ) Single lane movement is available;multi-lanes movement is available;dispersed evenly is achievable;
6 ) Set up a channel, good sealing, expand the warehouse utilization space. Compared with ordinary shelves, it can improve the warehouse utilization rate of about 80%;
7 ) Fewer channels, no need to find channels when accessing goods, high storage efficiency;
8 ) The structure of the electric mobile rack is simple, the operation is simple, not only the operation process is safe and reliable, but also the emergency movement when the power is cut off;
9 ) Electric mobile racks only need to be equipped with forward forklifts or balanced forklifts to be used. Electric mobile shelves have low operation requirements for forklifts;
10 ) With anti earthquake dumping function;
11 ) Protective measures such as emergency stop switches, photoelectric access barriers, manual release systems, proximity sensors as well as photoelectric safety barriers are in place to ensure the safety of workers and goods;







Electric mobile racking system



 Single Deep Heavy Duty Pallet Rack



Electric Mobile Racking · Warehouse Storage Rack · Made In China








CASE





Electric mobile racking system



Electric Mobile Racking System

Electric Mobile Racking SystemElectric Mobile Racking System





Electric Mobile Racking · Warehouse Storage Rack · Made In China






Ensure the quality of Huayide racking products



1

The raw material of the shelf is customized from China's large steel group of high quality carbon steel, durable and strong, to ensure the quality of the product from the source.

2

The shelf welding adopts dioxygen protection welding, the welding joint has good cracking resistance, small welding deformation, beautiful forming, and does not need slag cleaning.

3

Each column and beam of the shelf are designed by professional personnel with professional technology and cut by professional equipment, so as to ensure the accurate size of the shelf.

4

Professional spray before treatment, oil removal, rust removal, phosphating, powder, and then in high temperature oven baking molding, wear-resistant, rust proof.







Electric Mobile Pallet Racking



Warehouse Storage Rack  www.heavyracking.com



Electric Mobile Pallet Rack Rail Free Racking Warehouse Storage Rack Electric Mobile Racking 14



Electric Mobile Pallet Rack · Warehouse Storage Rack · Made In China
